• Axle diameter  70-80 mm.
• Plate-to-plate spacing 590 mm.
• Axle center-to-center distance 600-670 mm.

Mask nr. 10004083 – 10004084 – 10004085.

Distance between skellets: 65 mm.

Thickness skellets: 16 mm.

Teeth: Cat 1U3302.

All Buckets from H. Serup Olesen A/S can be delivered with Attachment according to the wishes of the customer.

Transport measurement: L: 1775 mm W: 1250 mm H: 1350 mm.

Mask no. 10004081 – 10004082.

Distance between skellets: 65 mm.

Thickness skellets: 20 mm.

Teeth: Cat 1U3352

All Buckets from H. Serup Olesen A/S can be delivered with Attachment according to the wishes of the customer.

Transport measurement: L: 1800 mm W: 1500 mm H: 1350 mm.

Mask no. 10004079 – 10004080.

Distance between skellets: 65 mm.

Thickness skellets: 20 mm.

Teeth: Cat 1U3352

All Buckets from H. Serup Olesen A/S can be delivered with Attachment according to the wishes of the customer.

Transport measurement: L: 1800 mm W: 1500 mm H: 1200 mm.

Mask no. 10004077 – 10004078.

Bottom: 400 mm.

Top: 1400/1600 mm.

Open measurement: 1310/1600 mm.

All Buckets from H. Serup Olesen A/S can be delivered with Attachment according to the wishes of the customer.

Mask no. 10004075 – 10004076.

Bottom: 400 mm.

Top: 1400/1600 mm.

Open measurement: 1310/1600 mm.

All Buckets from H. Serup Olesen A/S can be delivered with Attachment according to the wishes of the customer.

Mask no. 10004088 – 10004089 – 10004090.

Bottom: 400 mm.

Top: 1700 mm.

Open measurement: 770 mm.

All Buckets from H. Serup Olesen A/S can be delivered with Attachment according to the wishes of the customer.

Transport measurement: L: 1000 mm W: 2000 mm H: 1000 mm.

Mask no. 10004072 – 10004073 – 10004074.

All Buckets from H. Serup Olesen A/S can be delivered with Attachment according to the wishes of the customer.

Transport measurement: L: 950 mm W: 2500 mm H: 1100 mm.

Mask no. 10004091 – 10004092 – 10004093 – 10004094.

Hight for filling: appx. 2900 mm.

Width for filling: 4000 mm.

Depth for filling: 2200 mm.

Adjustable angle.

Springs at the top for mechanical vibration.

Skellets ø40 mm.

Distance between skellets 50 mm. Can be changed to 140 mm.

Possible to separate for transport (see transport measurements above).

• Axle diameter 90 mm.
• Plate-to-plate spacing 750 mm.
• Axle center-to-center distance 750 mm.
